Substrates optimized for fabricating field-effect transistors (FETs), including Si, GaAs, diamond, graphene, with excellent properties, purity and uniformity.

SOUTH BOSTON, MA, UNITED STATES, April 11, 2023/EINPresswire.com/ -- UniversityWafer, Inc. offers a wide range of substrates for fabricating field-effect transistors (FETs), including silicon, gallium nitride, diamond, graphene, and more. These substrates have been optimized for FET fabrication, with excellent electrical and thermal properties, high purity, and uniformity.

Silicon substrates are the most commonly used substrate material for FETs due to their excellent electrical properties, availability of high-quality wafers, and lower cost. UniversityWafer offers silicon substrates with different doping levels, crystal orientations, and surface finishes to meet various FET fabrication needs.

Gallium nitride substrates are ideal for high-power and high-frequency FET applications due to their wide bandgap, high electron mobility, and excellent thermal conductivity. UniversityWafer offers gallium nitride substrates in different sizes and orientations to suit different FET fabrication processes.

Diamond substrates offer excellent thermal conductivity and electrical properties, making them suitable for high-power and high-frequency FET applications. UniversityWafer offers high-quality diamond substrates with different orientations, sizes, and surface finishes to meet various FET fabrication needs.

Graphene substrates offer high carrier mobility and low intrinsic resistance, making them suitable for high-speed and low-power FET applications. UniversityWafer offers graphene substrates with different sizes, shapes, and thicknesses to meet various FET fabrication needs.

Organic semiconductor substrates offer flexibility, low cost, and compatibility with solution-based processing techniques, making them suitable for flexible and printed electronics. UniversityWafer offers organic semiconductor substrates with different properties and characteristics to meet various FET fabrication needs.

All of UniversityWafer's substrates are made with high-quality materials and undergo rigorous quality control processes to ensure uniformity and consistency. Customers can also request customized substrate specifications and sizes to suit their specific FET fabrication needs.
